Urinal with concealed radar sensor LIVO
for an aesthetic and vandal-proof installation...
CERAMIC URINAL LIVO WITH RADAR CONCEALED DETECTION
Designed for public sanitary spaces with high attendance.
With its design shape, this 1-liter s-trap system urinal allows you to save on water, preserves the environment and eliminates unpleasant smells
Urinal shape also adapted for children; programmable flush for children (on request).
- Economical 1 L flush
- Easy to assemble thanks to the paper drill template
- Activation only when the urinal is used (takes into consideration the urine or water movement)
- Adjustable flushing time from 0,5 to 15,5 sec.
- Minimum use time adjustable before flushing from 6 to 15 sec.
- Adjustable settings by SLD04 remote control (no need to disassemble the urinal)
- Automatic flushing after 6 hours without being used
- Possibility to regulate a water flow by the stopcock
 |
 |
| By battery | By mains |
- Sensor
- Radar
- Detection details
- Concealed behind the ceramics
- Power supply
- 6V battery
230V mains operated
External 230/24V transformer - Consumption
- 10 W on 24 V ; 1.4 W on 6 V
- Material
- Ceramic
- Water inlet
- 1/2"
- Evacuation
- Ø 50 mm
- Pressure
- 1-6 bars
- Flow rate
- 12 LPM.
- Flush volume
- 1 L (adjustable 0.5 to 4 LPM.)
- Operation settings
- Adjustable by SLD04 remote control: detection sensitivity, flow time, interval rinse, temporary off...
- Dimensions
- L360 x P327 x H575 mm
- Warranty
- Electronics 5 years
- Connection gender
- Male
