Automatic direct flush kit, presence detection system
Electronic, recessed and vandal proof toilet flush
Automatic direct flush kit, presence detection system

Stainless steel 316 direct WC flush kit by sensor sensibility

touch free WC direct flush sensor...

RES-121P2-S1
€330.00 Tax Excl.

Stainless steel 316 wall mounted electronic WC flush trigger kit, for a direct flush.

Flush is triggered once the user leaves, after the sensor detects users presence or voluntarily approaching hands near the sensor.

Vandal-proof

DOUBLE FLUSH VOLUME: the sensor determines if the direct flush needs to be compete or reduced depending on the distance and the presence period. = half-flush for less than one minute and complete flush for more that one minute.

OPTIONS:

  • Remote control RES-31
  • Anti-legionella hygienic flush 24 H.
  • matt black, matt gold Antique bronze finish
  • Angled flush pipe ref. S07291037
  • Stopcock ref. S09010014-1
  • 250 mm recessed threaded extension for thick walls ref. ...-TS
  • Removable detection from the front, recessed installation
  • IP68 transformer (ref. RES-292)
  • 230/12V IP 68 transformer to supply from 1 to 4 faucets (ref. RES-294)
  • Junction box 230/12V to supply up to 10 faucets (ref. RES-295)
Sensor
Infrared with optimized presets
Sensor range
700 mm (adjustable from 300 to 800 mm)
Power supply
9V battery
230/9V transformer
Solenoid valve
External M1 1/2''
Material
AISI 316 Stainless steel
Pressure
0.3 - 8 bars
Flush time
1 seconds. (adjustable)
Flush volume
Double flush 3-6 L (adjustable)
Operation settings
Adjustable by RES-31 remote control: detection sensitivity, activation delay, delay after user leaves, flush scale, temporary off, interval rinse 24 H.
Warranty
3 years. CE.

Stainless steel 316 wall mounted electronic WC flush trigger kit, for a direct flush.

Flush is triggered once the user leaves, after the sensor detects users presence or voluntarily approaching hands near the sensor.

Vandal-proof

DOUBLE FLUSH VOLUME: the sensor determines if the direct flush needs to be compete or reduced depending on the distance and the presence period. = half-flush for less than one minute and complete flush for more that one minute.

OPTIONS:

  • Remote control RES-31
  • Anti-legionella hygienic flush 24 H.
  • matt black, matt gold Antique bronze finish
  • Angled flush pipe ref. S07291037
  • Stopcock ref. S09010014-1
  • 250 mm recessed threaded extension for thick walls ref. ...-TS
  • Removable detection from the front, recessed installation
  • IP68 transformer (ref. RES-292)
  • 230/12V IP 68 transformer to supply from 1 to 4 faucets (ref. RES-294)
  • Junction box 230/12V to supply up to 10 faucets (ref. RES-295)

Sensor
Infrared with optimized presets
Sensor range
700 mm (adjustable from 300 to 800 mm)
Power supply
9V battery
230/9V transformer
Solenoid valve
External M1 1/2''
Material
AISI 316 Stainless steel
Pressure
0.3 - 8 bars
Flush time
1 seconds. (adjustable)
Flush volume
Double flush 3-6 L (adjustable)
Operation settings
Adjustable by RES-31 remote control: detection sensitivity, activation delay, delay after user leaves, flush scale, temporary off, interval rinse 24 H.
Warranty
3 years. CE.
