Electronic tap stainless steel ONE MINI brushed finish
pure line with concealed detection at the end of the spout
Technical sheet & documents
No technical sheet available for this reference. Request the sheet
Automatic tap ONE MINI in stainless steel AISI 316 brushed finish with infrared detection in the end of the spout, for a neat and refined aesthtic.
Other advantage, an efficient detection when the hands approach the sensor.
- For cold and pre-mixed water.
- Powered by 9V battery or 230/9V transformer.
- Low energy consumption, batteries last around 2 years or 250 000 cycles. Indicator light when batteries need changing.
- On the transformer version, solenoid valve double electric supply with a space for backup battery in case of a power cut.
- Sensor
- Infrared
- Detection adjustment
- Self-adjusting
- Detection details
- Sensor in the spout tip
- Power supply
- 9V battery
230/9V transformer - Hygienic rinse anti-legionella
- After 24 H of non-use
- Safety shut-off
- Shut-off after 90 seconds of uninterrupted use (adjustable)
- Solenoid valve
- External M1/2'' with filter
- Material
- AISI 316 stainless steel
- Finish
- Brushed
- Water supply
- Single supply
- Pressure
- 0.3 - 8 bars
- Max. eligible temperature
- 70°C
- Flow rate
- 4 LPM (1.9 LPM upon request)
- Operation settings
- Adjustable by RES-31 remote control: sensor range, flow time, periodic rinse, temporary stop...
- Warranty
- 3 years
- Certification
- CE
ACS - Water supply details
- Single supply: cold water or pre-mixed water (mixed upstream)
Automatic tap ONE MINI in stainless steel AISI 316 brushed finish with infrared detection in the end of the spout, for a neat and refined aesthtic.
Other advantage, an efficient detection when the hands approach the sensor.
- For cold and pre-mixed water.
- Powered by 9V battery or 230/9V transformer.
- Low energy consumption, batteries last around 2 years or 250 000 cycles. Indicator light when batteries need changing.
- On the transformer version, solenoid valve double electric supply with a space for backup battery in case of a power cut.
- Sensor
- Infrared
- Detection adjustment
- Self-adjusting
- Detection details
- Sensor in the spout tip
- Power supply
- 9V battery
230/9V transformer - Hygienic rinse anti-legionella
- After 24 H of non-use
- Safety shut-off
- Shut-off after 90 seconds of uninterrupted use (adjustable)
- Solenoid valve
- External M1/2'' with filter
- Material
- AISI 316 stainless steel
- Finish
- Brushed
- Water supply
- Single supply
- Pressure
- 0.3 - 8 bars
- Max. eligible temperature
- 70°C
- Flow rate
- 4 LPM (1.9 LPM upon request)
- Operation settings
- Adjustable by RES-31 remote control: sensor range, flow time, periodic rinse, temporary stop...
- Warranty
- 3 years
- Certification
- CE
ACS - Water supply details
- Single supply: cold water or pre-mixed water (mixed upstream)
