SMART automatic hand dryer over sink

complementary to the water and soap faucet

Reference SM-25-AB

Unit price

€875.00 Tax Excl.

Finish

Chrome
Matt black
Copper PVD
Matte Gold PVD

Ask a question

The SMART automatic hand dryer for washbasins is designed to take up minimal space and provide fast, efficient drying times.

It generates a flow of hot air for optimal user comfort.
Matching as a trio with the wall-mounted faucet and soap dispenser, this all-in-one set improves hygiene, and simplifies hand washing and drying.
SMART hand dryer is available in chromed brass or in high resistance brushed AISI 316 stainless steel.

Easy to dry hands right after washing
Water drops directly into the sink, simplifying the cleaning process
Design to be integrated in all sanitary facilities
Power and volume are adjustable
HEPA filter

Perfect combination with the SMART water (Ref. RES-15) and soap (Ref. RES-32) faucets for a 3 spout matching set above the sink, ensuring a complete hand washing cycle.

ADVANTAGE: The separate water spout and hand dryer outlet prevent soap splashes when hands covered with soap are brought under the tap for washing.

OPTION:

RES-31 remote control

Sensor: Self-adjusting infrared
Sensor range: 170 mm ± 20 mm, adjustable
Adjustable from 80 to 450 mm
Voltage supply: 220-240 V 50/60Hz. 6.1-6.7 A. 1.34 – 1.6 KW.
Electrical insulation: Class I
Protection rating: IP34
Standby consumption: 0.3 - 0.4 W
Safety shut-off: Shut-off after 90 seconds of uninterrupted use or in case of overheating
Security: Automatic shut-off if used irregularly for more than 60 seconds
Engine with security thermostat at 95° C
Thermal fuse stops heating element at 142°C
Material: Brass
Finish: Brushed
Chromed
Matte Black (minimum quantity, please contact us)
Matte Gold (minimum quantity, please contact us)
Power: 1450 W adjustable (350-650 W engine / 450-800 W heating element)
Air speed: 75 - 100 m/s adjustable
Drying time: Less than 30 seconds
Sound level: Min. 70 dB – max. 73.7 dB
Filter: HEPA
Operation settings: Adjustable by RES-31 remote control: sensor range, drying time, security shut-off time, temporary stop (cleaning)
Dimensions: Faucet Ø42 x D216 x H205 mm
Motor housing W200 x D185 x H319 mm
Warranty: 3 years

SM-25_Technical-sheet.pdf SM-25-2D-ftl-view.dwg SM-25-3D.dwg SM-25.ifc SM-25.obj
