Stainless steel wash trough with splashback INTER-7-D for wall-mounted tapware
Stainless steel wash trough with protective splashback
Technical sheet & documents
No technical sheet available for this reference. Request the sheet
Wash trough with splashback for wall-mounted tapware, made from AISI 441 stainless steel.
The splashback protects the wall from splashes and makes cleaning easier. It helps maintain hygiene by preventing water from building up on wall surfaces.
- No rear deck; H120 mm splashback protecting the wall from water splashes and dirt, to be glued or screwed.
- Robotic welding with no grooves in the corners, preventing bacteria from building up.
- Inner angles along the length of the basin > 90° for easier cleaning.
- Flat bottom that takes a 15 l bucket.
- Bowl depth 142 mm. Central perforated 1 1/2" waste grid.
- Quick and easy installation with 4 fixing points.
- Complies with standard EN 14296 on the load resistance of sanitary appliances.
- Accessible to people with reduced mobility from a width of 100 cm.
 |
 |
 |
 |
 |
| Rounded corners to prevent injury on impact | Pressed waste with no water retention or screws, for hygiene and easy cleaning | High-quality welding. Inner angles greater than 90° | Enough space for a bucket | Lift-up stainless steel grid option, as a rest or draining rack |
| Stainless steels are rust-free thanks to their chromium content, which gives them remarkable resistance to corrosion and wear (a "passive" surface film). Type 441 chromium steel is no exception, and is used successfully in major applications such as sinks, washing machine drums and exhaust systems… |
- Material
- AISI 430/441 stainless steel
- Detailed composition
- Sides 1.5 mm - tank 0.8 mm
- Stainless steel thickness
- 0.8 mm
1.5 mm - Finish
- Brushed
- Evacuation
- Ø 40 mm
- Waste connection
- 1 1/2"
- Fixing
- Wall mounted
- Dimensions
- W600 x D400 x H406 mm
W1000 x D400 x H406 mm
W1200 x D400 x H406 mm
W1400 x D400 x H406 mm
W1500 x D400 x H406 mm
W1800 x D400 x H406 mm
W2000 x D400 x H406 mm
W2100 x D400 x H406 mm
W2400 x D400 x H406 mm
W2800 x D400 x H406 mm
W3000 x D400 x H406 mm
Wash trough with splashback for wall-mounted tapware, made from AISI 441 stainless steel.
The splashback protects the wall from splashes and makes cleaning easier. It helps maintain hygiene by preventing water from building up on wall surfaces.
- No rear deck; H120 mm splashback protecting the wall from water splashes and dirt, to be glued or screwed.
- Robotic welding with no grooves in the corners, preventing bacteria from building up.
- Inner angles along the length of the basin > 90° for easier cleaning.
- Flat bottom that takes a 15 l bucket.
- Bowl depth 142 mm. Central perforated 1 1/2" waste grid.
- Quick and easy installation with 4 fixing points.
- Complies with standard EN 14296 on the load resistance of sanitary appliances.
- Accessible to people with reduced mobility from a width of 100 cm.
|
|
|
|
|
| Rounded corners to prevent injury on impact | Pressed waste with no water retention or screws, for hygiene and easy cleaning | High-quality welding. Inner angles greater than 90° | Enough space for a bucket | Lift-up stainless steel grid option, as a rest or draining rack |
| Stainless steels are rust-free thanks to their chromium content, which gives them remarkable resistance to corrosion and wear (a "passive" surface film). Type 441 chromium steel is no exception, and is used successfully in major applications such as sinks, washing machine drums and exhaust systems… |
- Material
- AISI 430/441 stainless steel
- Detailed composition
- Sides 1.5 mm - tank 0.8 mm
- Stainless steel thickness
- 0.8 mm
1.5 mm - Finish
- Brushed
- Evacuation
- Ø 40 mm
- Waste connection
- 1 1/2"
- Fixing
- Wall mounted
- Dimensions
- W600 x D400 x H406 mm
W1000 x D400 x H406 mm
W1200 x D400 x H406 mm
W1400 x D400 x H406 mm
W1500 x D400 x H406 mm
W1800 x D400 x H406 mm
W2000 x D400 x H406 mm
W2100 x D400 x H406 mm
W2400 x D400 x H406 mm
W2800 x D400 x H406 mm
W3000 x D400 x H406 mm
