Vertical electronic faucet to integrate behind mirror

for a streamlined washbasin area with impeccable hygiene

Reference RES-88

Unit price

€295.00 Tax Excl.

Finish

Chrome

Power supply

Mains
Battery

Ask a question

Automatic vertical electronic tap designed for behind-mirror installation, to be integrated above the washbasin.

Activation is via infrared detection: water flows as soon as you place your hands under the spout in the indicated area. As soon as your hands leave the detection zone, the water stops automatically.

Fully touchless, this tap eliminates manual operation and helps reduce the spread of germs. Temperature and flow rate are preset for simple, comfortable, and safe use.

30 cm minimum distance under the sensor, avoiding any shining.

OPTIONS:

Remote control RES-31
Brushed, matt black, matt gold finish (minimum quantity)
Limited flow rate 1,9 LPM
IP68 transformer (ref. RES-292)
230/12V IP 68 transformer to supply from 1 to 4 faucets (ref. RES-294)
Junction box 230/12V to supply up to 10 faucets (ref. RES-295)
Soap dispenser matching design

Sensor: Self-adjusting infrared
Power supply: 9V battery
230/9V transformer
Hygienic rinse anti-legionella: After 24 H of non-use
Safety shut-off: Shut-off after 90 seconds of uninterrupted use (adjustable)
Solenoid valve: External M1/2'' with filter
Material: Brass
Water supply: Single supply: cold water or pre-mixed water (mixed upstream)
Pressure: 0.5 - 8 bars
Max. eligible temperature: 70°C
Flow rate: 5 LPM (on demand 1,9 LPM)
Operation settings: Adjustable by RES-31 remote control: sensor range, flow time, periodic rinse, temporary stop...
Warranty: 3 years. CE. ACS.

RES-88-89_Technical-sheet.pdf RES-88_Dimensions.pdf RES-88_2D.dwg

Automatic vertical electronic tap designed for behind-mirror installation, to be integrated above the washbasin.

Fully touchless, this tap eliminates manual operation and helps reduce the spread of germs. Temperature and flow rate are preset for simple, comfortable, and safe use.

30 cm minimum distance under the sensor, avoiding any shining.

OPTIONS:

Remote control RES-31
Brushed, matt black, matt gold finish (minimum quantity)
Limited flow rate 1,9 LPM
IP68 transformer (ref. RES-292)
230/12V IP 68 transformer to supply from 1 to 4 faucets (ref. RES-294)
Junction box 230/12V to supply up to 10 faucets (ref. RES-295)
Soap dispenser matching design

Sensor: Self-adjusting infrared
Power supply: 9V battery
230/9V transformer
Hygienic rinse anti-legionella: After 24 H of non-use
Safety shut-off: Shut-off after 90 seconds of uninterrupted use (adjustable)
Solenoid valve: External M1/2'' with filter
Material: Brass
Water supply: Single supply: cold water or pre-mixed water (mixed upstream)
Pressure: 0.5 - 8 bars
Max. eligible temperature: 70°C
Flow rate: 5 LPM (on demand 1,9 LPM)
Operation settings: Adjustable by RES-31 remote control: sensor range, flow time, periodic rinse, temporary stop...
Warranty: 3 years. CE. ACS.
